| Specification規格 : | |||
| 印刷座 | Printing Station | (Sets) | 10 |
| 上金油 | Flexo varnishing station(Part) | (Sets) | 1 |
| 傳動齒輪 | Gearing | (cp） | 1/8* |
| *大紙寬 | Max.paper width | (mm) | 260 |
| *大印刷寬 | Max.printing width | (mm) | 250 |
| 送紙徑(*大) | Unwind roll dia.max | (mm) | 800 |
| 復卷徑（*大） | Rewind roll dia.Max | (mm) | 800 |
| 印刷長度 Print length |
*長max. *短min. |
(mm) (mm) |
460.375 190.5 |
| *大印刷速度 | Max.printing Speed | (m/min) | 100 |
| 機械重量 | 浮重Net weight | (kgs) | 8800 |
| Machine weight | 毛重Gross weight | (kgs) | 9800 |
| 主機馬達Main Motor | 380V(kw) | 11 | |
| 耗電與馬達 | 勻墨馬達（10個）Stirring motor(10PCS） | (w) | 2000 |
| Power&Motor | UV乾燥10套(UV dryer 11sets) 5KW/PC 10LAMPS | ||
| 7KW/PC lLAMPS | (kw) | 57 | |
| 機械尺寸 | Machine Size L*W*H | (m) | 8.0×1.6×2.2 |
| 標準配備： | Standard Accessories | ||
| 印刷座 | 十座 | Printing station | 10Sets |
| 版胴（尺寸任選） | 五套 | Printing cylmder(Size Optional) | 5Sets |
| UV | 十座 | UV dryer | 10Sels |
| 修紙邊 | 一套 | Paper Slitting System | 1Set |
| 工具 | 一套 | Tools | 1Set |
| 貼版臺 | 一套 | Block setting table | 1Set |
| 對邊器 | 一套 | Automatic web guiding system | 1Set |
| 接紙臺 | 一套 | Splicing platform | 1Set |
| 上金油座(含UV系統) | 一套 | Flexo varnishing Systemwith UV dryer | 1Set |
| 可樂娜表面處理器 | Corona treater (Foil can be treated) | ||
| 膠裹和背面印刷設備 | Back Side printing device | ||
| 圓墊模切座 | Rotary Dia Cutting Devica | ||
| 靜電消除器 | Electrostatic Eliminator | ||
| 上護膜（有、無底紙均可） | Opp Laminating System | ||
| 選購配備： | The Selects and Purchases Equipments: |
| 冷燙系統 | Cole foil system |
| 凹版印刷系統 | Intaglio plate printing system |
| 圓綱版印刷系統 | Rotary screen printing system |
| 切單張系統 | Cuts the single sheet systam |
| 靜態觀測系統 | Static state observation system |
| 冷卻系統 | Cooling system |
| 適用材料 | Suitable materials： |
| 貼紙、積層材、BOPP膜、收縮膜、 石化附屬環保材料和特殊材料等 |
Adheslve paper，Laminate mate rialsBOPP Film,Shrinkable film Styrofoam and other Spacial materials |
| 適用刀膜 | Suitable Die-Cutting: |
| 磁性圓刀模、雕刻圓胴刀模 | Magnetic cylinder, fiexble plate,rotary die cut,．Rotary hard dies. |
| 印版版材：樹脂版 | Standard Plate Making Reference:photopolymer Plate |
| 版材硬度45°~55°度 | Plate Hardness:45°~55° |
| 版材厚度0.95mm | Plate Thickness:0.95mm |
| 洗刷深度0.69mm（參考） | Depth:0.69mm(Referencel） |
